Description
The Health o meter 2620KL ADA-compliant wheelchair scale features a 1,000 lb capacity, Platinum Corada certification, dual 1:8-slope ramps, an extra-large foldable platform with 2-inch edge protection, and EMR connectivity
Features
- Handles up to 1,000 lb / 454 kg
- Fully ADA-compliant and Platinum certified by Corada, meeting 2024 US Access Board MDE Standards
- Dual ramps with 1:8 running slope allow safe roll-on access from either end of the scale
- Extra-large 40" x 32" platform with a non-skid surface gives wheelchairs plenty of room to position safely
- 2-inch edge protection on both the platform and ramps helps prevent wheels from rolling off during weighing
- Anti-slip caution tape on the ramps adds a visible safety cue for caregivers and patients
- Platform folds up for storage when not in use, freeing up floor space in busy clinical environments
- 4 built-in wheels (including 2 casters) make repositioning the scale between rooms a one-person job
- Swiveling display head rotates 180° so the readout is always visible regardless of which side the caregiver is working from
- Antimicrobial keypad helps reduce surface contamination between patient interactions
- Reads to the nearest 0.2 lb / 0.1 kg for clinically reliable results
- Automatic BMI calculation
- Switches instantly between pounds and kilograms, with an optional lockout to enforce a single unit
- Pre-tare, hold/release, reweigh, and recall functions streamline the weighing process in busy clinical settings
- Everlock® permanent unit lock prevents accidental unit changes after configuration
- Parent/child weighing function makes it easy to weigh patients who cannot stand independently
- High-contrast color TFT-LCD screen is easy to read in a variety of lighting conditions
- Connects to EMR/EHR systems via USB (optional Pelstar® wireless technology upgrade)
- Powered by 100–240V universal adapter or with 6 D batteries
Specs
Technical Specs
| Platform Size | 40" x 32¼" x 1⅞" (1016 mm x 819 mm x 48 mm) |
|---|---|
| Ramp Size | 32¼" W x 16" D (819 mm x 406 mm) |
| Edge Guard Size | 40" W x ⅛" D x 2" H (1016 mm x 3 mm x 51 mm) |
| Footprint (Operating) | 71½" W x 45⅛" D x 48¾" H |
| Max Load | 1,000 lb (454 kg) |
| Accuracy | 0.2 lb / 0.1 kg |
| Display | 2¾" x 1½" High-Contrast Color TFT-LCD; 3/8" digit size |
| Connectivity | USB (Optional Pelstar® Wireless Technology) |
| Power | 100–240V AC Adapter (ADPT30, included) 6 D Batteries (not included) |
| Portability | 4 wheels (2 casters) |
| Product Weight | 126 lb (57 kg) |
| Certifications | ADA Compliant – Platinum Certified by Corada |
| Warranty | 2-year limited manufacturer warranty |
Documents
User Guides
Shipping
Shipping
Due to the size and weight, this item ships via freight LTL tractor-trailer. (Think 18 wheeler). Shipping is not included.
