Description
The Detecto 7150-AC ADA-compliant wheelchair scale features a 1,000 lb capacity, NTEP-certified clinical accuracy, 1:8 shallow-angle ramps, integrated side guide rails, and EMR/EHR connectivity in a portable, foldable design.
Features
- Supports up to 1,000 lb / 450 kg — suitable for a wide range of patient sizes
- Designed to meet ADA accessibility standards for wheelchair-using patients
- Extra-long 40-inch platform gives wheelchairs more room to position safely and comfortably
- Gradual 1:8-angle approach ramps make rolling on and off easier for caregivers and patients
- Built-in side rails help keep wheelchairs centered and reduce repositioning during weighing
- Only 2 inches off the ground — minimizing the ramp incline and making access as simple as possible
- NTEP-certified accuracy meets clinical and legal-for-trade requirements
- Weighs to the nearest 0.2 lb / 0.1 kg for precise, repeatable readings
- Automatic BMI calculation saves staff from manual conversions
- Reads in pounds or kilograms — switch instantly depending on preference or protocol
- Single-pass weighing with a one-touch tare keeps patient throughput efficient
- Connects directly to your EMR/EHR system to reduce manual data entry and transcription errors
- Standard RS232 and USB ports; optional Wi-Fi, Bluetooth, and wired Ethernet available
- Large, easy-to-read LCD display with 7/8-inch weight digits — visible from across the room
- 19-key sealed membrane keypad is color-coded for quick, intuitive operation
- Frame folds flat in seconds using a quick-release lever — no tools required
- Built-in transport wheels let one person move the scale between rooms without assistance
- Collapses to just 11.4 inches deep, fitting easily into a closet or along a hallway wall
- Arrives 90% pre-assembled — ready to use shortly after it comes out of the box
- Includes AC adapter; also runs on 6 C batteries for locations without a nearby outlet
Specs
Technical Specs
| Platform Size | 40" x 36" x 2.2" |
|---|---|
| Ramp Size | 36" W x 17.4" L |
| Overall Dimensions | 75" W x 45" H x 40" D |
| Folded Depth | 11.4" |
| Max Load | 1,000 lbs (450 kg) |
| Accuracy | 0.2 lb / 0.1 kg divisions; 5,000 divisions max resolution |
| Connectivity | RS232 Serial, USB (Optional Wired Ethernet, Wi-Fi & Bluetooth) |
| Power | AC Adapter Model 6800-1045 (included) 6 C Batteries (not included) |
| Net Weight | 143 lb (65 kg) |
| Shipping Weight | 190 lb (86 kg) |
| Operating Temperature | 14°F to 104°F (-10°C to 40°C) |
| Certifications | NTEP Certified |
Shipping
Shipping
Due to the size and weight, this item ships via freight LTL tractor-trailer. (Think 18 wheeler). Shipping is not included.
