Midmark Heine EN200 Otoscope and Ophthalmoscope Wall Kit

Write a Review
SKU:
A-095-12-210-166
  • K180 Midmark Heine Diagnostic Instrument Wall Kit
  • K180 Midmark Heine Ophthalmoscope Full View
  • K180 Midmark Heine Ophthalmoscope Detailed
  • K180 Midmark Heine Otoscope Lens
  • K180 Midmark Heine Otoscope Detailed
  • K180 Midmark Heine Otoscope Side
  • K180 Midmark Heine Ophthalmoscope Side
  • BETA 400 Midmark Heine Otoscope Side
  • BETA 400 Midmark Heine Otoscope Angled
  • BETA 200 Midmark Heine Ophthalmoscope
  • EN200 Midmark Heine BETA 400 LED Otoscope and BETA 200 LED Ophthalmoscope wall kit
  • BETA 200 Midmark Heine Otoscope Head
  • BETA 200 Midmark Heine Ophthalmoscope Head
  •  BETA 400 LED Otoscope and BETA 200 LED Ophthalmoscope Midmark Heine
  • EN200 Midmark Heine Otoscope and Ophthalmoscope with tip dispenser and sphygmomanometer
  • EN200 Midmark Heine Otoscope and Ophthalmoscope with tip dispenser
  • EN200 Midmark Heine Otoscope and Ophthalmoscope with sphygmomanometer
YOUR PRICE $899.00
Frequently bought together:

Description

What comes in the box:

-EN200 Wall Transformer
     -Otoscope with polycarbonate, 11.5' (3.5 m) corded handle
     -Ophthalmoscope with polycarbonate, 11.5' (3.5 m) corded handle

EN200 Wall Transformer:
• Two handles can be used at the same time for efficiency
• Handles switch on and off automatically when placed into the charger, and are ready to remove as soon as you want to use them, with adjustable brightness levels.
• Integrated anti-theft system helps prevent unauthorized removal of instrument heads, ensuring they are always available where they are needed and reducing replacement costs.
• LEDHQ instruments with 100,000-hour LED life reduces maintenance and service costs.
• Improves hygiene and reduces risk of cross-contamination with a flat, space- saving housing—no opening and no on/off switch.


K180 Otoscope

  1. 3x Magnification Allows for more detail of anatomical structures and easy recognition of foreign bodies.

  2. Fiber Optic Illumination Ensures homogenous, bright illumination and an unobstructed view of the ear canal and tympanum.

  3. Polycarbonate Housing Durable and shock-resistant for a long product life.

  4. Xenon Halogen Illumination (XHL) Provides a bright, white light in truer color. Our instruments have exceptionally high CRI values at greater than 97, a special index for red colors (R9: >93), and a color temperature of 3,300 K.

  5. Swiveling View Window Viewing window is permanently attached to avoid being lost or broken, and swivels for instrument use and complete cleaning of the instrument head.









K180 Ophthalmoscope

1. Spherical Optics Precision HEINE optics with proprietary glare mitigating coatings for crisp, clear images of the fundus.

2. Xenon-Halogen Illumination Provides a bright, white light in truer color. Our instruments have exceptionally high CRI values at greater than 97, a special index for red colors (R9: >93), and a color temperature of 3,400 K.

3. 27 Diopter Settings Lens range from -35D to +40D for precisely focused images in all examining situations.

4. 5 Apertures Choice of five apertures: large spot, small spot, red-free, fixation star and grid, and slit.

5. Dust-Resistant Design Protects the optical components and ensures maintenance-free operation.

6. Polycarbonate Housing Durable and shock-resistant for a long product life.







BETA 400 LED Otoscope

1. Continuous Brightness Control (Patent Pending) Control brightness between 100% and 3% with one-finger operation.

2. Metal Housing Durable metal structure for a long product life and a sleek appearance.

3. Flip-up View Window Viewing window is permanently attached, and flips up for instrument use and the complete cleaning of the instrument head.

4. Scratch-Resistant Glass Conventional otoscopes come with a plastic viewing window. We’ve improved upon this design using scratch-resistant glass to keep your view clean and free of obstructions for the life of your product.

5. Precision Optics Multi-coated, precision optics deliver high resolution, distortion-free images with exceptional depth of field and a large field of view.






BETA 200 LED Ophthalmoscope

1. Continuous Brightness Control (Patent Pending) Control brightness between 100% and 3% with one-finger operation.

2. Metal Frame Optical components are flush-mounted on a cast-aluminum frame inside the device, making the instrument shock-resistant.

3. 27 Diopter Settings Lens range from -35D to +40D for precisely focused images in all examining situations.

4. Scratch-Resistant Glass The multi-coated viewing window is built using scratch-resistant glass to keep your view clean and free of distractions for improved diagnosis.

5. 6 Apertures Six apertures available with red-free filter, including slit, fixation star, cobalt blue filter, large spot, pinhole and hemispot for all examination situations.

6. Dustproof Design Protects the optical components from dust and ensures maintenance-free operation.

Product Features Heine BETA 400 Heine BETA 200 Heine K180
  heine-beta-400-head.png heine-beta-200-head.png heine-k180-head.png
Magnification  4.2x  3x  3x
 Light Source LED (XHL option available)   LED (XHL option available) XHL (Halogen)
Color Temperature  LED: typ. 3,500 K
XHL: 3,300 K
 LED: typ. 3,500 K
XHL: 3,300 K
 XHL: 3,300 K
CRI  Typ. ≥ 97
R9 > 93
Typ. ≥ 97
R9 > 93
Typ. ≥ 97
R9 > 93
Luminous Flux (without tip/with 4-mm tip)  LED: typ. 15 lm/typ. 5.9 lm
XHL: 6 lm/3.8 lm
LED: typ. 15 lm/typ. 5.9 lm
XHL: 6 lm/3.8 lm
 XHL: 6.42 lm/2.6 lm
Brightness Control  Continuous between 100 - 3%  Continuous between 100 - 3%  Continuous between 100 - 3%
Depth of Field  Wide range of exceptionally sharp spatial images  Wide range of exceptionally sharp spatial images  Fixed
 Field of View  3 mm 3 mm  3 mm
 Housing Metal  Metal  Polycarbonate
Window  Scratch-resistant multi-coated glass  Scratch-resistant multi-coated glass  Acrylic
Light Source Life Expectancy   LED: typ. 100,000 hrs
XHL: typ. 30 hrs
LED: typ. 100,000 hrs
XHL: typ. 30 hrs
XHL: typ. 30 hrs
Instrumentation  Optics flip open  Swiveling Window  Swiveling Window
Cleaning  Smooth surfaces, wide-opening window allows for easy cleaning   Smooth surfaces, wide-opening window allows for easy cleaning Smooth surfaces, wide-opening window allows for easy cleaning
 Pneumatic Testing Sealed connection for optimal testing   Sealed connection for optimal testing Available



Product Features Heine BETA 200 Heine K180
  heine-beta-200-ophthalmascope-head.png heine-k180-ophthalmoscope-head.png
Light Source LED (XHL option available) XHL (Halogen)
Color Temperature LED: 3,300 K
XHL: 3,400 K
XHL: 3,400 K
CRI Typ. 95
R9 typ. 93
Typ. 95
R9 typ. 93
Brightness Control Continuous between 100 - 3% with one-finger operation Continuous between 100 - 3% with one-finger operation
Optics Aspherical Optical System (AOS) elliptical beam, reflex free Precision spherical optics with proprietary glare-mitigating coating
Magnification 15x 15x
Field of View 5-10° 5-10°
Sealing Dustproof Dust-resistant
Frame Aluminum Polycarbonate
Window Scratch-resistant glass Scratch-resistant glass
Light Source Life Expectancy LED: typ. 100,000 hrs
XHL: typ. 30 hrs
XHL: typ. 30 hrs
Lenses/Rekoss Disc 27 27
Range of Lenses 27 single lenses
+1D steps from 1-10, 15, 20, 40
-1D steps 1-10, 15, 20, 25, 35
+1D steps from 1-10, 15, 20, 40 -1D steps 1-10, 15, 20, 25, 35
Apertures 5 - large spot, small spot, hemispot, slit, fixation star with grid 3 - large spot, small spot, slit
Filters Red-free with all apertures, cobalt blue Red-free, cobalt blue






Tech Specs

Otoscope Nominal Voltage

3.0 V – 3.7 V

Otoscope Nominal Current

XHL: max. 760 mA
LED: max. 350 mA

Otoscope Class

Internally powered

Otoscope Device Classification According to IEC 62471

Exempt

Applied Part

Type BF

Ophthalmoscope Nominal Voltage

3.0 V – 3.7 V

Ophthalmoscope Nominal Current

XHL: max. 760 mA
LED: max. 350 mA

Ophthalmoscope Class

Internally powered

Ophthalmoscope Device Classification According to ISO 10942

Group B

Ophthalmoscope Device Classification According to ISO 15004-2

Group 2

System Regulatory Compliance

IEC 60601-1 Edition 3.1

Shipping

Free shipping is included for this item.



View AllClose

More Info

Manufacturer:
Heine
Manufacturer Part:
EN200
Ships Via:
Fedex
Warranty:
10 Years
